27” Inch Industrial display
27” Industrial LED 4k Display with Touch
Features:
- The PW-ILD-270-4T is a-Si TFT-LCD display with an integral LED backlight system.
- 27” inch diagonally measured active display area with Full HD resolution (3840*2160 pixel resolution array).
- Large size 27” Display Monitor supports LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important
- Hi-brightness and Hi-contrast display
- Wide input option of DVI, HDMI and VGA
- PCAP touch included
Specifications
Specifications
| Model#. | PW-ILD-270-4T |
|---|---|
| Active Screen Size | 27 inches diagonal – IPS Display screen |
| Touch | Projected Capacitive Touch (PCAP touchscreen) |
| Resolution | 3840(RGB)×2160, UHD 163PPI |
| Active View Area | 596.16(W)×335.34(H) mm |
| Aspect Ratio | 16:9 (H:V) |
| Input options | DVI, HDMI, VGA, USB(only for touch) |
| Color Depth | 16.7M 72% NTSC |
| OSD | Rear bottom OSD buttons |
| Mounting | Vesa/Wall |
| Luminance, White | 400cd/m2 (Center 1point ,Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle (CR>10) | 89/89/89/89 (Typ.) |
| Power Consumption | 230V AC input |
| Environment | Operating Temp.: 0 ~ 60 ºC ; Storage Temp.: -20 ~ 60 ºC |
| Weight | Approx. 10 kgs |
| Surface Treatment | Hard coating(2H), Anti-glare treatment |
| Possible Display Type | Landscape Enabled |
| Mechanical | TBD |
| Warranty | 12 months (extended warranty on demand) |
| Lead time | 6-8 weeks ARO |
| Ordering Information | |
|---|---|
| PW-ILD-270-4T | 27″ Industrial Display Monitor with Touch |
| PW-ILD-270-4RT | 27″ Rugged Display Monitor with Touch |
