15.6″ Inch Industrial Display
15.6” Industrial LED Display with Touch
Features:
- The PW-ILD-156-T is a Color Active Matrix Liquid Crystal Display Monitor with an integral LED backlight system.
- It can present a palette of more than 16.7M colors.
- This size 15.6” Display Monitor supports LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important
- Hi-brightness and Hi-contrast display
- Wide input option of DVI, HDMI and VGA
- PCAP touch included
- Extra Wide Operating Temperature
Specifications
Specifications
| Model#. | PW-ILD-156-T |
|---|---|
| Active Screen Size | 344.16(W)×193.59(H) mm |
| Touch | Projected Capacitive Touch (PCAP touchscreen – optional) |
| Resolution | 1920(RGB)×1080, FHD 141PPI |
| Active View Area | Aluminium alloy front with IP65 |
| Aspect Ratio | 16:9 (H:V) |
| Input options | DVI, HDMI, VGA, USB (only for touch) |
| Color Depth | 16.7 Million colors |
| OSD | Bottom OSD buttons |
| Mounting | Vesa/Wall/Rack |
| Luminance | 500cd/m² (Center 1 point ,Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle (CR>10) | 85/85/80/80 (Typ.)(CR≥10) |
| Power Consumption | 230V AC input / 12V DC input (both options available) |
| Environment | Designed to comply Op Temp.: -20 ~ +60℃; Storage Temp.: -30 ~ 70℃ |
| Weight | Approx. 8 kgs |
| Surface Treatment | Hard coating(2H), Anti-glare treatment |
| Possible Display Type | Portrait mode |
| Mechanical | TBD |
| Warranty | 12 months (extended warranty on demand) |
| Lead time | 6–8 weeks ARO |
| Ordering Information | |
|---|---|
| PW-ILD-156-T | 15.6″ Industrial Display Monitor with Touch |
| PW-ILD-156-RT | 15.6″ Rugged Display Monitor with Touch |
